Low Lift Safety Relief Valve

Keep equipment safe, prevent accidents and reduce losses.

The safety valve is selected based on equipment, fluid characteristics, operating temperature, set pressure, and discharge capacity. And also to apply various conditions, such as the use of the environment, accuracy, and stability, must be carefully evaluated.

" 317 "   Safety relief valve series we provide is characterized by regulating of pressure in valve rising and blowing-out when actuated and is the smallest and lightest valve, and also can be used in non-corrosive gases (air, oxygen, nitrogen, etc.) steam and liquids, such as water and oil.

View:

(SV-B27/SVP-B27) БРОНЗОВЫЙ ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ (СТАРАЯ МОДЕЛЬ: S3W-A)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B27)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B29) БРОНЗОВЫЙ ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ (СТАРАЯ МОДЕЛЬ: S3W-LR)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B29)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-B9A) БРОНЗОВЫЙ ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B9A)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B9L) БРОНЗОВЫЙ ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B9L)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-BS9A) БРОНЗОВЫЙ ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН, КОРПУС – БРОНЗА / ДИСК – НЕРЖАВ. СТАЛЬ

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: SUS304.
SEAL: PTFE (SVP-BS9A)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-BS9L) БРОНЗОВЫЙ ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН, КОРПУС – БРОНЗА / ДИСК – НЕРЖАВ. СТАЛЬ

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: SUS304.
SEAL: PTFE (SVP-BS9L)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-BS9DA/SVP-BS9DA) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, БРОНЗОВЫЙ (1x2)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-BS9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B9DA) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, БРОНЗОВЫЙ (1x2)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS. (1*2)
SEAL: PTFE (SVP-B9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B9DL) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, БРОНЗОВЫЙ (1x2)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS. (1*2)
SEAL: PTFE (SVP-B9DL)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-S9A) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ НЕРЖАВ. СТАЛЬ 304

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8.
SEAL: PTFE (SVP-S9A)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-S9L) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, НЕРЖАВ. СТАЛЬ 304

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8.
SEAL: PTFE (SVP-S9L)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-S9DA) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, НЕРЖАВ. СТАЛЬ 304 (1x2)

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-S9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-S9DL) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, НЕРЖАВ. СТАЛЬ 304 (1x2)

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-S9DL)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-S8DA) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, НЕРЖАВ. СТАЛЬ 316 (1x2)

ST.ST.316 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8M. (1*2)
SEAL: PTFE (SVP-S8DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-S8DL) ПРЕДОХРАНИТЕЛЬНЫЙ КЛАПАН НИЗКОГО ДАВЛЕНИЯ, НЕРЖАВ. СТАЛЬ 316 (1x2)

ST.ST.316 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8M. (1*2)
SEAL: PTFE (SVP-S8DL)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITH LEVER)
